CDB5571
3. HARDWARE DESCRIPTION
3.1
Absolute Maximum Ratings
Observe the following limits to ensure the CDB5571 component ratings are not exceeded.
? CS5571
– The absolute maximum supply voltage that can be applied to the +3.3V power supply
connection is +3.6V.
– The absolute maximum power supply voltage that can be applied between pins VL and V1-
is 6.1 V.
? CS3004
– The absolute maximum power supply voltage that can be applied between the +2.5V and
-2.5V power supply connections is +5.5V.
3.2
Power Supply
Power supply connections and requirements are specified in Table 1. below.
Table 1. Power Supply Connections
Power Supply
Requirement
+2.5 V DC, ±5%, <50 mA
-2.5 V DC, ±5%, <50 mA
+3.3 V DC, ±5%, <50 mA
Power Supply
Connection
E5
E9
E16
Associated
Ground Return
E3
E7
E13
Associated
Test Points
TP2, TP1 (GND)
TP4, TP3 (GND)
TP6, TP5 (GND)
Important: It is recommended that all power supplies be isolated from utility ground to prevent the intro-
duction of a ground loop. One ground connection may already exist through the serial port connection to
utility ground. Using the Cirrus Logic CapturePlus II system simplifies making connections to the
CDB5571 by providing electrical isolation between the two.
Using twisted/shielded wire will reduce electrical noise induced onto the power supply cables.
Power supplies are to be adequately regulated and sufficiently low noise to meet the application require-
ments.
3.3
3.3.1
Analog Section
Analog Input Buffers
The analog input signal connections to the input buffers are made at the IN_A and IN_B connectors, as
specified in Table 2.
Table 2. Analog Input Connections
Analog Input
Input Signal
Channel
IN_A
IN_B
Connection
J10
J11
Voltage Range
-2.048 V to +2.048 V
-2.048 V to +2.048 V
Impedance
50 Ohms
50 Ohms
There are two analog input channels on the evaluation board. Each analog input channel consists of a
low-noise amplifier configured as a unity gain non-inverting buffer. The buffers utilize a Cirrus Logic
CS3004 precision, low-noise, low-voltage, dual opamp.. These op-amps enable both the inputs and out-
puts of the analog input buffer to operate virtually rail to rail. The channel input impedance is 50 Ohms.
6
DS768DB4
